The Molded Fiber 4-Cup Takeout Beverage Carrier is engineered to hold four takeaway beverage cups in one secure, unified packaging unit. Designed for cafes, QSR chains, beverage franchises, delivery services, and catering operations, this carrier streamlines multi-drink order assembly and ensures safe transit.
Key Product Advantages
High-Efficiency Multi-Drink Order Handling
Consolidates up to four beverages into a single handling unit, significantly reducing order assembly time, streamlining drive-through operations, and simplifying customer handoffs.
Precision Molded Compartments
Each cup rests inside an individually contoured pocket that supports the lower section of the cup, minimizing tipping, sliding, and lateral movement during transport.
Engineering Based on Actual Geometry
Because nominal volume (e.g., 16 oz) varies across cup manufacturers, our carriers are engineered against complete physical profiles-including top/bottom diameter, height, wall slope, lid design, and filled weight-to ensure a secure fit.
Compact Nesting & Freight Optimization
High-density nesting profiles minimize back-of-house storage space and optimize ocean and truck freight efficiency per unit.
Technical Specifications
|
Specification Item |
Details / Range |
|
Product Name |
Molded Fiber 4-Cup Takeout Beverage Carrier |
|
Capacity |
4 Cups |
|
Material Options |
Sugarcane Bagasse / Bamboo Pulp / Recycled Wood Pulp |
|
Dimensions (L x W x H) |
215 mm x 215 mm x 45 mm (or Custom) |
|
Compatible Top Diameter |
80 mm - 95 mm |
|
Compatible Bottom Diameter |
55 mm - 68 mm |
|
Color Options |
Natural Brown / Bleached White / Custom Colors |
|
PFAS / Fluorine Status |
PFAS-Free / Fluorine-Free options available |
|
Compliance & Standards |
FDA, EU Food Contact, FSC, BPI Certified Compostable |
|
Packaging Configuration |
300 units per carton (Custom packing available) |
|
Custom Tooling / OEM |
Available (Custom pocket dimensions, depth, and logo embossing) |
Operational Challenges & Engineering Solutions
|
Operational Challenge |
Engineering Solution |
|
Carrying multiple loose drinks |
Groups four drinks into one sturdy handling unit to speed up fulfillment. |
|
Spills and shifting during transit |
Deep molded pockets stabilize the cup base and reduce lateral movement. |
|
Non-standard cup shapes |
Custom tooling services available based on physical cup samples or 2D/3D CAD files. |
|
High storage and logistics costs |
High nesting ratio maximizes warehouse storage capacity and reduces freight costs. |
|
Strict environmental regulations |
100% plant-based fiber options compliant with global PFAS-free and compostability standards. |
Logistics & OEM Customization
Storage & Logistics Optimization
Designed with a focus on total cost of ownership (TCO):
• High Nesting Density: Reduces stack height and maximizes carton volume.
• Pallet Efficiency: Cartons are sized to fit standard ISO pallets, maximizing shipping container loading capacity.
Custom Mold Development (OEM/ODM)
If standard carriers do not fit your proprietary cups, custom mold tooling is available.
• Customization Options: Pocket diameter, depth, cup spacing, structural wall thickness, and custom logo embossing.
• Required Info for Custom Quotes: Top diameter, bottom diameter, total height, filled weight, hot/cold beverage application, and target annual volume.
FAQ
